Single Mode Fiber Optic Connectors Square Sc Apc Connector In Telecommunications Networks

Name: Single Mode Fiber Optic Connectors Square Sc Apc Connector In Telecommunications Networks
Brand: Liocrebif
Price: 5000 USD

Buy cheap Single Mode Fiber Optic Connectors Square Sc Apc Connector In Telecommunications Networks product

Brand Name : Liocrebif

Model Number : LKF-SC

Certification : GJB 9001C-2017

Place of Origin : China

MOQ : 1

Price : 5000-25000CHY

Payment Terms : T/T

Supply Ability : 10000

Delivery Time : 2-4 weeks

Packaging Details : Wooden box/Cardboard box/Container

Color&Classification : LKF-SC

Brand : Liocrebif

Output format : RS422

Application : Telecommunications networks, Cable television, Gigabit Ethernet, Active or passive equipment terminals, Industrial, medical, and military applications

Original Place : China

Dimension : Determined by model

Contact Now

Essential details

MOQ:1

Specification Number:LKF-SC

Product Introduction

SC is one of the most common connectors in single-mode network equipment, frequently found on optical terminal units. It utilizes a 2.5 mm ceramic ferrule and, unlike ST or FC connectors, is a push-fit device requiring no rotation—a snap-in square interface. The “SC” in SC fiber optic connectors stands for Square Connector. Its rectangular form factor makes it an affordable option with easy insertion/removal, minimal insertion loss variation, high compression strength, and high installation density, contributing to its widespread adoption.

Table1 SC Main Parameters

Category	Specification Requirements
End-Face Requirements	400X Compliant with IEC 61300-3-35
Insertion Loss	≤0.3dB
Return Loss	≥45dB (SM, PC); ≥60dB (SM, APC)
Repeatability	≤0.2dB
Ferrule Type	PC, UPC, APC with optional floating end
Covering	0.9Hytrel, 2.0/3.0mm PVC, armored empty conduit, etc. available
Operating Temperature	-40°C to +85°C
Compliance Standard	YD_T 1272.3-2015

Main Features

High stability and reliability.

Low insertion loss, high return loss.

Excellent polishing standards.

End-face geometry parameters comply with GR-326Core.

Available in single-core or dual-core cables with Ф0.9, Ф2.0, or Ф3.0 diameters.

Applications

Telecommunications networks

Cable television

Gigabit Ethernet

Active or passive equipment terminals

Industrial, medical, and military applications

Dimensions Of The External Structure

Single Mode Fiber Optic Connectors Square Sc Apc Connector In Telecommunications Networks
